Replacement sensor used for some Amana, Crosley, Estate, Ikea, Inglis, Kenmore, KitchenAid, Magic Chef, Maytag, Roper, and Whirlpool oven models.
Directly Replaces: WPW10181986 W10181986, W10131826, WPW10181986VP, 8273902, 1394200, AP6016450, EAP11749737, PD00003022, PS11749737.
Features:
- Senses and sends the oven temp reading to the control board.
- Used on some gas and electric units.
- Includes (1) Sensor Probe and 2-Wire Harness Assembly.
Specifications:
- Material: Metal.
- Electrical Specs: 1000 Ohm.
- Probe Dimensions: 7"L x 1-3/4"W x 3/4"H.
- Additional Dimensions: Harness and Plug measure 5"L.
Compatible Models:
Don't see your model listed? Submit this form to get help finding the right part.
Failure Symptoms: Uneven baking / Lack of temperature control.
How to test: The sensor can be tested by using a multimeter. As temperature rises, the resistance measurement also rises. Oven temperature problems can be caused by other things, but this is one of the more common causes.
Repair Tip: The oven sensor varies its resistance to electrical current as the temperature varies. If the oven doesn't bake evenly, the oven sensor resistance might be incorrect.
For small variations, you may be able to re-calibrate the resistance with the control board. Check the owners manual for directions on how to do this on your model.
