Replacement high limit thermostat used for some Amana, Kenmore, Maytag, and Samsung dryer models.
Directly Replaces: WP35001092, 35001092, DC47-00018A, 503497, T-O-D 60T11, 1122485, 2068549, AH2038383, AP4201898, AP6008682, EA2038383, EAP2430930, EAP11741822, PD00002011, PD00004704, PS11741822, PS2038383, PS2430930, PS4205217.
Features:
- Safety switch actuated by temperature change to keep the dryer from overheating.
- L260-50F Thermostat.
- Includes (1) High Limit Thermostat.
Specifications:
- Color: Black / Gray.
- Material: Metal / Plastic.
- Electrical Specs: 125/250V.
- Overall Dimensions: 1-1/2"L x 1-1/8"W x 2"H.
- Additional Dimensions: 1 1/8" between mounting holes (center to center); ¼" spade terminals.
Compatible Models:
Don't see your model listed? Submit this form to get help finding the right part.
Repair Skill Level: 2 | Beginner to Moderate
Minimal disassembly (if any) and some basic tools may be needed.
Part Description: The hi-limit thermostat is a safety switch actuated by temperature change to keep the dryer from overheating.
Failure Symptoms: Dryer may heat too long, or may not heat at all.
Testing: Use a multimeter to test it for continuity in the thermostat. If there is no continuity it should be replaced.
Bonus Tip: Overloading the dryer is a common cause of broken dryer parts. Learn your dryer's max capacity to get the best longevity out of it.
